OBSBOT Tail Air AI-Powered 4K PTZ Streaming Camera

RM2,699.00

  • Advanced AI Auto Tracking

  • UHD Resolutions up to 4K@30fps / 1080P@60fps

  • Seamless NDI Connectivity

  • Multi-port Connections

  • Exclusive App Support

10 in stock

SKU: OBS-TAILAIR Category: Tag:
OBSBOT

1-Year Official Warranty by Obsbot Malaysia

***************************************************

OBSBOT Tail Air AI-Powered 4K PTZ Streaming Camera

[TECH SPECS]

Appearance

  • OBSBOT Tail Air



Size & Weight

  • Working State:69.65*73.25*132.5mm

  • Off State:69.65*73.25*135.5mm

  • Weight:344.5g





AI chip

  • Integrated AI chip, Trillions of calculations per second



Camera

  • Image sensor:1/1.8'' CMOS

  • Macro pixel size:2.0μm*2.0μm

  • Effective pixels:8.4 million

  • Effective pixel resolution:3856×2176

  • Lens system:8 Optical Lenses

  • Zoom range:4X digital zoom

  • ISO range:100-6400

  • Exposure value:±3EV

  • Electronic shutter speed:1/8000 s to the limit of frames per second

  • Focus:Auto Focus/Manual Focus

  • Aperture:ƒ/1.8

  • Equivalent focal length:23mm

  • White balance:2000K-10000K

  • Gyroscope:6-axis Gyroscope





Shooting

  • Photo resolution:4K, 1080P

  • Video resolution:4K@30/25/24 fps, 1080@60/50/48/30/25/24 fps

  • Max video storage bit rate:H264: 100Mbps, H265: 80Mbps

  • Video format:MJPEG, H264, H265





2-axis gimbal

  • Gimbal installation:Non-removable

  • Controllable range:Pan: ±150°; Tilt: -65°~32°

  • Mechanical range:Pan: ±160°; Tilt: ±90°

  • Max controllable speed:120°/s

  • Angle jitter:±0.02°





Audio

  • Audio input: Built-in Two MEMS Microphones, Built-in 3.5mm TRS Connector (AUX), Support MIC IN/LINE IN

  • Audio modes:Noise Reduction/Stereo Sound

  • Audio format:AAC/PCM



Wi-Fi

  • Operating frequency:2.4 G/5.8 GHz

  • Signal transmission range:2.4G 140m, 5.8G 80m

  • Transmission power:2.4 GHz: <18 dBm（FCC/CE/SRRC/MIC), 5.1 GHz: <15 dBm（FCC/CE/SRRC/MIC), 5.8 GHz: <15 dBm（FCC/CE/SRRC）



Bluetooth

  • Bluetooth protocol:BLE 5.0

  • Bluetooth operation frequency range:2.400 GHz to 2.4835 GHz



USB

  • USB:2.0



Charger & Battery

  • Input:5V/2A

  • Quick charge protocol:Don't Support

  • Charging time:90 Minutes (Power off status)

  • Operating time:
    154 minutes

  • *Tested in a laboratory environment while recording 1080p/30fps video and should be used for reference only

  • Battery type:Lithium Polymer(Li-po)

  • Battery capacity:1500mAh

  • Battery energy:11.4Wh

  • Battery voltage:7.6V



Auxiliary Functions

  • Gesture Control



Auxiliary App

  • Obsbot Start



Memory card type

  • Memory card type: Micro SD Card (up to 512GB) -exFAT (Recommended)/FAT32; U3 card (minimum write speed 30MB/S) recommended.



Operating environment

  • Camera working environment temperature: -10°C-40°C

  • Battery charging ambient temperature: -10°C-40°C

  • Battery operating ambient temperature: -10°C-40°C



⚠ Charging will stop when the battery temperature exceeds 45°C.

For example, when connected to an external power supply, if the battery temperature exceeds 45°C, the camera will stop charging and will be powered directly from the external power supply.

Weight 0.40 kg
Dimensions 20.00 × 12.00 × 11.00 cm
