JBL BAR 300 5.0-channel compact all-in-one soundbar with MultiBeam & Dolby Atmos | Built-In Wi-Fi | 260W output power

1 Year Official JBL Malaysia Warranty

******************************************

JBL BAR 300 5.0-channel compact all-in-one soundbar with MultiBeam & Dolby Atmos | Built-In Wi-Fi | 260W output power



Dolby Atmos® and MultiBeam™ Surround Sound

Immerse yourself in theater-quality 3D surround sound. Hear extraordinary sound effects from everywhere in the room, without the need for extra surround speakers.



Built-In Wi-Fi with AirPlay, Alexa Multi-Room Music and Chromecast built-in™

Get ready to explore. Access over 300 online music streaming services through AirPlay, Alexa MRM and Chromecast built-in™. Enjoy all of your favorite audio content, Internet radio, and podcasts in high definition. The Wi-Fi connection also allows automatic software updates, so you can always enjoy the latest features.



260W output power

With 260 watts of total output power, the JBL Bar 300 transforms your movies, music and games into immersive sound experiences.





Audio Specifications:



Total speaker power output (Max @THD 1%)260W

Soundbar transducer4x (46×90)mm racetrack drivers, 2x 0.75" (20mm) tweeters

Frequency response50Hz – 20kHz (-6dB)

Audio inputs1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)



Dimensions

Soundbar dimensions (W x H x D)820 x 56 x 103.5 mm / 32.3’’ x 2.2’’ x 4.1’’

Soundbar weight2.5kg/5.5 lbs

Packaging dimensions (W x H x D)1060 x 120 x 170 mm/ 41.7" x 4.7" x 6.7"

Packaging Weight4.1 kg / 9 lbs



Control and Connection Specifications

USB portType A

USB rating5V DC, 0.5A

Supporting file formatMP3

MP3 codecMPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3

MP3 sampling rate16 – 48 kHz

MP3 bitrate80 – 320 kpbs

Bluetooth version5.0

Bluetooth profileA2DP 1.2, AVRCP 1.5

Bluetooth transmitter frequency range2400 MHz – 2483.5 MHz

Bluetooth transmitter power<15 dBm (EIRP)

Wi-Fi networkIEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)

2.4G Wi-Fi transmitter frequency range2412 – 2472 MHz (2.4 GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)

2.4G Wi-Fi transmitter power< 20 dBm (EIRP)

5G Wi-Fi transmitter frequency range5.15 – 5.35GHz, 5.470-5.725GHz, 5.725 – 5.825GHz

5G Wi-Fi transmitter power5.15-5.25GHz <23dBm, 5.25-5.35GHz & 5.47-5.725GHz <20dBm, 5.725-5.825GHz <14dBm (EIRP)





What's in the box?

• 1 x Soundbar

• Remote control with 2 x batteries

• Power cords (up to 4pcs depending on region SKUs)

• 1 x HDMI cable

• 2 x L-shape wall-mount bracket with screws

• Quick start guide

• Safety Instruction and Warranty Card

• Wall mount template
