JBL BAR 1000 7.1.4-channel soundbar with detachable surround speakers | MultiBeam | Dolby Atmos | DTS:X | 880W Output

1 Year Official JBL Malaysia Warranty

******************************************

JBL BAR 1000 7.1.4-channel soundbar with detachable surround speakers | MultiBeam | Dolby Atmos | DTS:X





General Specifications:



Model: BAR 1000

Sound system: 7.1.4 channel

Power supply: 100 – 240V AC, ~ 50/60Hz

Networked standby power: < 2.0W

Operating temperature: 0°C – 45°C





Audio Specifications:



Total speaker power output (Max @THD 1%): 880W

Soundbar output power (Max @THD 1%): 440W

Surround speaker output power (Max @THD 1%): 2x 70W

Subwoofer output power (Max. @THD 1%): 300 W

Soundbar transducer: 5x (46×90)mm racetrack drivers, 3x 0.75" (20mm) tweeters, 2x 2.75" (70mm) up-firing full-range drivers

Surround speaker transducer: 0.75" (20mm) tweeters, 2.75" (70mm) up-firing full-range drivers

Subwoofer transducer: 10” (260mm)

Frequency response: 33Hz – 20kHz (-6dB)

Audio inputs: 1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)







Dimensions:



Total soundbar dimensions (W x H x D): 1194 x 56 x 125mm / 47" x 2.2" x 4.9"

Main soundbar dimensions (W x H x D): 884 x 56 x 125 mm / 34.8" x 2.2" x 4.9"

Detachable surround speaker dimensions (each) (W x H x D): 155 x 56 x 125 mm / 6.1" x 2.2" x 4.9"

Subwoofer dimensions (W x H x D): 305 x 440.4 x 305 mm / 12" x 17.3" x 12"

Soundbar weight: 3.7 kg / 8.2 lbs

Detachable surround speaker weight (each): 1.4kg / 3.1 lbs

Subwoofer weight: 10 kg / 22 lbs

Packaging dimensions (W x H x D): 1000 x 375 x 475 mm/ 39.4" x 14.8" x 18.7"

Packaging Weight: 19.4 kg / 42.7 lbs





Control and Connection Specifications:



USB portType:  A

USB rating: 5V DC, 0.5A

Supporting file format: MP3

MP3 codec: MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3

MP3 sampling rate: 16 – 48 kHz

MP3 bitrate: 80 – 320 kpbs

Bluetooth version: 5.0

Bluetooth profile: A2DP 1.2, AVRCP 1.5

Bluetooth transmitter frequency range: 2400MHz – 2483.5MHz

Bluetooth transmitter power: <15dBm (EIRP)

Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)

2.4G Wi-Fi transmitter frequency range2412 – 2472MHz (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 channels)

2.4G Wi-Fi transmitter power< 20dBm (EIRP)

5G Wi-Fi transmitter frequency range5.15 – 5.35GHz, 5.470-5.725GHz, 5.725 – 5.825GHz

5G Wi-Fi transmitter power5.15-5.25GHz <23dBm, 5.25-5.35GHz & 5.47-5.725GHz <20dBm, 5.725-5.825GHz <14dBm (EIRP)

2.4G wireless frequency range2406 – 2474MHz

2.4G wireless power＜10dBm (EIRP）





What's in the box?

• 1x Main soundbar

• 2x Detachable wireless surround speakers

• 1x Wireless subwoofer

• Remote control with 2 x batteries

• Power cords (up to 8pcs depending on region SKUs)

• 1 x HDMI cable

• 2 x L-shape wall-mount bracket (main bar) + 2 x U-shape wall-mount bracket (for surround speakers) kit with screws

• 4 x Side caps

• Quick start guide

• Safety instruction and Warranty card

• Wall mount template
