This pocket-sized multi-adapter provides all the ports you need for maximum productivity. It has 9 functions in 1 sleek adapter. It allows you to connect your laptop to a 4K monitor. It also connects to an ultrawide monitor. The USB-C multi-adapter gives you 2 USB Type-A ports for additional peripherals and 1 USB Type-A port with BC 1.2 to fast-charge your mobile device.
With USB-C® Power Delivery 3.0, the adapter offers both upstream and downstream charging when connected to a USB-C® power adapter. It also provides direct access to a wired network and to your SDTM & microSD memory cards.
The JCD383 is perfect for small workspaces, home offices and for on-the-go!
SYSTEM REQUIREMENTS
- Available USB-C® port that supports DisplayPort alt mode and USBTM Power Delivery 2.0 or 3.0. Please refer to the manufacturer of your hardware for more information on your device.
HARDWARE
Warranty: 2-Year Limited
Host Connector: 1 – USB-C® Male
Video Output: 1 – HDMI Female
Power Source: Bus-powered or self-powered
Network Interface: RJ45 (Gigabit Ethernet)
Audio Supported: Yes
Ports
1 – USB-C® 3.0 (upstream & downstream charging, power delivery 3.0, and data transfer)
2 – USB Type-A 3.1 Gen 1
1 – USB Type-A 3.1 Gen 1 with BC 1.2
1 – SD & microSD
1 – 4K HDMI
1 – RJ45 Gigabit Ethernet
PERFORMANCE
Maximum Display Resolution: 3840 x 2160
Maximum Display Refresh Rate: 30 Hz
Maximum Data Transfer Rate: 5 Gbps
Displays Supported: 1
Compatible Networks: 10/100/1000 Base-T, auto-negotiating
Audio Channe:l 2.1 via HDMITM
POWER
Power Delivery: 100W
Power Consumption: 500 mA
Input Current: Up to 5A
Input Voltage: Up to 20V
Output Current: Up to 4.25A
Output Voltage: Up to 20V
PHYSICAL SPECIFICATIONS
Color: Silver
Enclosure Type: Aluminum
Cable Length: 5.4 in. (137 mm)
Product Height: 4.13 in. (105 mm)
Product Width: 1.97 in. (50 mm)
Product Depth: 0.65 in. (16.5 mm)
Product Weight: 2.75 oz (78g)
Storage Temperature: 14 to 149°F (-10 to 65°C)
Storage Humidity: < 85% non-condensing
Operating Temperature: 32 to 118°F (0 to 48°C)
Operating Humidity: < 85% non-condensing
